Name: Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000
Brand: Beijing Ding Ding Future Technology Co.Ltd
SKU: Sierra 25 - 110/230-277
Price: 1 USD
Availability: InStock

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000

MOQ

1 USD

Precio

Caracteristicas Galería Descripción de producto Pida una cita

Caracteristicas

Especificaciones

Marca: CE+T

Número de modelo: Sierra 25 - 110/230-277

Nombre del producto: Convertidores/UPS

Número de pieza: T721D50201

Voltaje de salida de CA: 110VDC

Datos de entrada de CA: 230 Vac / 11.8 A, 240 Vac / 11.0 A y 277 Vac / 9.5 A

Datos de entrada de corriente continua: El valor de las emisiones de CO2 de los motores de combustión renovable se calculará en función de l

Eficacia: DC/AC: > 93,7%

Eficacia: AC/AC: > 96% / > 93,7% / > 93,7%

G.W.: 6kg

Información básica

Lugar de origen: CN

Nombre de la marca: CET

Certificación: CE UL

Número de modelo: Sierra 25 - 110/230-277

Pago y Envío Términos

Detalles de empaquetado: cajas de madera

Tiempo de entrega: 6-8 semanas

Capacidad de la fuente: 500 juegos / mes

Galería

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000

Descripción de producto

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 0

CE+T Sierra 25 Bidirectional Industrial Power Converter 2.7kW–2MW Sierra 25 - 110/230-277 T724D50010

Description:

Sierra 25 – 48/230-277 can be used as a UPS to secure AC & DC loads and charge the batteries.

The 3 all bidirectional ports allow for multiple innovative applications such as grid reinjection, peak shavings,

phase balancing or energy sharing through DC distribution, among many others.

By using several modules, we can offer solutions for three-phase (3x400Vac + N) infrastructures.

The module can be integrated in small or large cabinets to reach up to 2 MW.

With our new Inview S monitoring, you can benefit from a unique experience.

The total output power per module is 2.7 kW, limited to 2.4 kW for each AC or DC port.

Key Features:

Secure AC & DC loads;
Many innovative applications;
Compatible with Inview S;
Modularity: from 2.7 kW to 2 MW;
From small to large systems.

Versions:

4 modules can be integrated into 2U high shelves to provide up to 10.8 kW (AC + DC)

Parameters:

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 2

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 3

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 4

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 10

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 11

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 14

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 15

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 16

Modular High-Density Power: CE+T Sierra 25 Hot Swappable Bidirectional Converter Sierra 25-110/230-277 T724D50000 17
